Dartmoor Kinder MTB Sparrow Junior Mullet 27.5"/26" | Matt Sand Storm

27.5"/26" wheel size for young people with a height of 140 - 160 cm
Seeing a kid's big smile while shredding the trails is inspiring. That's why we're introducing a new frame series aimed at smaller riders.
We've opted for a mullet setup with a smaller rear wheel to offer more agility and riding fun, while a larger front wheel provides more comfort, traction and confidence for those first steps into the MTB world.
Included

• derailleur hanger
• Small parts for brake hose and derailleur cable attachment

matt Sand Storm, AL 6061-T6
[right]FRAME SIZE
one size
FORK
X-Fusion RC32 27.5", travel 120mm, axle 9mm, tapered
HEADSETS
Dartmoor Blink OEM
DERAILLEUR
Microshift AdventX RD-M6205GM (with clutch) 1x10
SHIFTER
Microshift AdventX SL-M9605-R, 10-speed
BRAKES
2-piston hydraulic brakes, rotors 160mm
CRANKSET
Prowheel Charm 2-pcs crankset with external BB bearings, 155mm
CHAINRING
30T, BCD 76mm
CASSETTE
Microshift CS-H104, 11-48T
CHAIN
KMC X10
PEDALS
Dartmoor Candy
RIMS
Dartmoor Raptor 27.5" (front)/Raptor 26" (rear),32H, F/V, tubeless ready
FRONT HUB
W/sealed bearings, 9mm QR, 32H
REAR HUB
W/sealed bearings, 135x10mm QR, 32H
FRONT TIRE
Vee Tire Flow Snap 27x2.35, Wire, MPC
REAR TIRE
Vee Tire Flow Snap 26x2.4, Wire, MPC
HANDLEBAR
Dartmoor Tornado 710mm, Ø31.8mm
STEM
Dartmoor Viper, Ø31.8mm
GDartmoor Trail Junior
SEATPOST
alu 6061, 3matt Sand Storm
WEIGHT
12.50kg (w/o pedals)FRAME[/right]


Technical data
[table][tr][td]Wheel size:[/td]
[td]27.5"/26"[/td]
[/tr]
[tr][td]Material:[/td][/td]
[td]AL 6061-T6[/td]
[/tr]
[tr][td]Weight:[/td][/td]
[td]2.05kg[/td]
[/tr]
[tr][td]Colors:[/td][/td]
[td]Matt Sand Storm[/td]
[/tr]
[tr][td]Sizes:[/td][/td]
[td]one size[/td]
[/tr]
[tr][td]Recommended suspension fork:[/td][/td]
[td]120-140mm[/td]
[/tr]
[tr][td]Maximum chainring size:[/td][/td]
[td]32 Z[/td]
[/tr]
[tr][td]Max. Tire size:[/td]
[td]27.5 x 2.4" / 26 x 2.4"[/td]
[/tr]
[tr][td]Rear axle:[/td][/td]
[td]135x10mm[/td]
[/tr]
[tr][td]Seat post/seat clamp:[/td][/td]
[td]30.9mm/34.9mm[/td]
[/tr]
[tr][td]Headset:[/td][/td]
[td]IS42/IS52[/td]
[/tr]
[tr][td]Brake mount:[/td][/td]
[td]PM 160[/td]
[/tr]
[tr][td]max. disc brake:[/td][/td]
[td]180[/td]
[/tr]
[tr][td]Bottom bracket type:[/td][/td]
[td]BSA/euro 73[/td]
[/tr]
[/table]
